Rotary Solenoids

Geeplus rotary solenoids offer an angle of up to 95° (depending on size) and starting torque of up 13Nm. The robust design allows a high life expectancy of up to 50 million cycles!

Selecting a Rotary Solenoid

Rotary Solenoid by Geeplus

3 Ball Rotary Solenoids

The rotary movement in our rotary solenoids is converted from a linear motion by the mechanical incorporation of an inclined plane.

There are three uniform spiral grooves (called “ball races”) that are stamped into both the case and the armature. The ball races convert the linear motion to rotary, while also providing the bearing system for the rotary movement.

Geeplus Proportional rotary solenoid

Check out this video on our innovative semi-proportional rotary solenoid design!

Notable Characteristics of Geeplus Rotary Solenoids:

• Angle of rotation up to 95° (depending on type)
• Starting torque up to 13Nm (gross starting torque at 20°C)
• High life expectancy: Up to >50 million cycles
• Mounted by studs
• Fast response time: Switching times <5ms possible (depending on size and load)
• Numerous standard options (metric or SAE threads, shaft on either side, return spring, dust cover, tapped holes in armature plate)
• Optional reduced noise option (special dust cover)
Viscous damping for size 491 and 591 (smooth operation, soft endstop, less noise)

3-Ball Rotary Solenoids Part Number chart


ModelRotary Angle 25° (30° for 190)Rotary Angle 35°Rotary Angle 45°Rotary Angle 67.5°Rotary Angle 95°DimensionsData Sheet 3D Drawing
Starting Torque
at 100% ED*
(at 10% ED*)
Nm
Starting Torque
at 100% ED*
(at 10% ED*)
Nm
Starting Torque
at 100% ED*
(at 10% ED*)
Nm
Starting Torque
at 100% ED*
(at 10% ED*)
Nm
Starting Torque
at 100% ED*
(at 10% ED*)
Nm
D x H (mm).PDF.IGS
1900.04----20 x 17pdf logo3D logo
3010.022
(0.15)
0.017
(0.127)
0.012
(0.081)
--30 x 17pdf logo3D logo
3410.04
(0.31)
0.029
(0.23)
0.017
(0.16)
0.012
(0.075)
-34 x 21pdf logo3D logo
4010.104
(0.52)
0.069
(0.355)
0.035
(0.276)
0.022
(0.185)
0.012
(0.115)
40 x 25pdf logo3D logo
490
0.22
(1.39)
0.104
(0.84)
0.081
(0.725)
0.058
(0.45)
0.022
(0.185)
49 x 27pdf logo3D logo
4910.32
(1.39)
0.16
(0.96)
0.13
(0.79)
0.09
(0.52)
0.04
(0.24)
49 x 32pdf logo3D logo
5900.53
(3.2)
0.39
(2.14)
0.195
(1.26)
0.184
(1.0)
0.103
(0.6)
59 x 35pdf logo3D logo
5910.72
(3.45)
0.53
(2.27)
0.28
(1.36)
0.25
(1.07)
0.14
(0.64)
59 x 41pdf logo3D logo
7001.27
(4.9)
0.69
(4.37)
0.58
(3.42)
0.288
(2.01)
0.178
(1.21)
70 x 45pdf logo3D logo
8701.84
(11.3)
1.38
(7.35)
1.15
(6.2)
0.48
(3.34)
0.4
(1.95)
87 x 55pdf logo3D logo
8743.6
(13)
2.4
(8.7)
2.0
(7.4)
1.01
(3.9)
0.66
(2.2)
87 x 90pdf logo3D logo
